Extend the life of airborne video systems by quickly linking them to ARINC 818 architecture. The VCM is a flyable, rugged converter available in a number different protocols.
VIDEO CONVERTER MODULE (VCM)
USEFUL LINKS
{"items":["911cc4a9-3916-4b13-b2f0-4e4b826f4502","d7d546a6-96cf-4114-8517-aa297689630c","6e06ecdf-6061-4d42-919e-c6c5cab80cf9"],"styles":{"galleryType":"Strips","groupSize":1,"showArrows":true,"cubeImages":true,"cubeType":"fit","cubeRatio":"100%/100%","isVertical":false,"collageAmount":0.8,"collageDensity":1,"groupTypes":"1","oneRow":true,"imageMargin":0,"galleryMargin":0,"floatingImages":0,"chooseBestGroup":true,"smartCrop":false,"hasThumbnails":true,"enableScroll":true,"isGrid":false,"isSlider":false,"isColumns":false,"isSlideshow":false,"cropOnlyFill":false,"fixedColumns":0,"enableInfiniteScroll":true,"isRTL":false,"minItemSize":120,"rotatingGroupTypes":"","rotatingCubeRatio":"","gallerySliderImageRatio":1.3333333333333333,"numberOfImagesPerRow":3,"numberOfImagesPerCol":1,"groupsPerStrip":0,"borderRadius":0,"boxShadow":0,"gridStyle":1,"mobilePanorama":false,"placeGroupsLtr":false,"viewMode":"preview","thumbnailSpacings":5,"galleryThumbnailsAlignment":"bottom","isMasonry":false,"isAutoSlideshow":false,"slideshowLoop":false,"autoSlideshowInterval":4,"useCustomButton":false,"bottomInfoHeight":0,"titlePlacement":"SHOW_ON_HOVER","galleryHorizontalAlign":"center","galleryTextAlign":"center","galleryVerticalAlign":"center","scrollSnap":true,"itemClick":"expand","fullscreen":true,"allowSocial":false,"allowDownload":false,"allowTitle":false,"allowDescription":false,"loveButton":false,"loveCounter":false,"videoPlay":"auto","scrollAnimation":"NO_EFFECT","scrollDirection":1,"overlayAnimation":"NO_EFFECT","arrowsPosition":0,"arrowsSize":23,"watermarkOpacity":40,"watermarkSize":40,"useWatermark":true,"watermarkDock":{"top":"auto","left":"auto","right":0,"bottom":0,"transform":"translate3d(0,0,0)"},"loadMoreAmount":"all","defaultShowInfoExpand":1,"allowTitleExpand":true,"allowDescriptionExpand":true,"allowLinkExpand":true,"expandInfoPosition":0,"allowFullscreenExpand":true,"fullscreenLoop":false,"galleryAlignExpand":"left","addToCartBorderWidth":1,"addToCartButtonText":"","slideshowInfoSize":200,"playButtonForAutoSlideShow":false,"allowSlideshowCounter":false,"hoveringBehaviour":"APPEARS","thumbnailSize":120,"magicLayoutSeed":1,"imageHoverAnimation":"NO_EFFECT","calculateTextBoxHeightMode":"AUTOMATIC","calculateTextBoxWidthMode":"PERCENT","textBoxHeight":0,"textBoxWidth":200,"textBoxWidthPercent":50,"textImageSpace":10,"textBoxBorderRadius":0,"textBoxBorderWidth":0,"textsVerticalPadding":0,"textsHorizontalPadding":0,"titleDescriptionSpace":6,"customButtonText":"","customButtonBorderWidth":1,"customButtonBorderRadius":0,"loadMoreButtonText":"Load More","loadMoreButtonBorderWidth":1,"loadMoreButtonBorderRadius":0,"imageInfoType":"NO_BACKGROUND","itemBorderWidth":0,"itemBorderRadius":0,"itemEnableShadow":false,"itemShadowBlur":20,"itemShadowDirection":135,"itemShadowSize":10,"imageLoadingMode":"BLUR","expandAnimation":"NO_EFFECT","imageQuality":90,"usmToggle":false,"usm_a":0,"usm_r":0,"usm_t":0,"videoSound":false,"videoSpeed":1,"videoLoop":true,"gotStyleParams":true,"selectedLayout":"3|bottom|1|fit|false|1|true","showVideoPlayButton":true,"galleryImageRatio":2,"sharpParams":{"quality":90,"usm":{}},"imageLoadingWithColorMode":"PICKED_COLOR","imageRatioType":"FIXED","numberOfDisplayedItems":3,"itemBorderColor":{"themeName":"color_15","value":"rgba(24,26,28,1)"},"itemShadowOpacityAndColor":{"themeName":"color_15","value":"rgba(24,26,28,0.2)"},"textBoxBorderColor":"color-5","textBoxFillColor":"color-2","alwaysShowHover":false,"isStoreGallery":false,"previewHover":false,"galleryLayout":3,"itemOpacity":{"themeName":"color_14","value":"rgba(70,75,78,0)"},"itemFont":{"style":{"bold":false,"italic":false,"underline":false},"family":"play","preset":"Heading-M","editorKey":"font_5","size":25,"fontStyleParam":true,"displayName":"Basic Heading","value":"font:normal normal normal 25px/1.4em play,sans-serif;"},"itemFontSlideshow":{"family":"avenir-lt-w01_85-heavy1475544","displayName":"Basic Heading","style":{"bold":false,"italic":false,"underline":false},"size":22,"preset":"Custom","editorKey":"font_5","fontStyleParam":true,"value":"font:normal normal normal 22px/27px avenir-lt-w01_85-heavy1475544,sans-serif;"},"itemDescriptionFontSlideshow":{"family":"avenir-lt-w01_35-light1475496","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":15,"preset":"Custom","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 15px/18px avenir-lt-w01_35-light1475496,sans-serif;"},"itemDescriptionFont":{"family":"avenir-lt-w01_35-light1475496","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":15,"preset":"Custom","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 15px/18px avenir-lt-w01_35-light1475496,sans-serif;"},"itemFontColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"itemFontColorSlideshow":{"themeName":"color_15","value":"rgba(24,26,28,1)"},"itemDescriptionFontColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"itemDescriptionFontColorSlideshow":{"themeName":"color_15","value":"rgba(24,26,28,1)"},"loadMoreButtonFont":{"family":"open sans","displayName":"Paragraph 2","style":{"bold":false,"italic":false,"underline":false},"size":14,"preset":"Body-M","editorKey":"font_8","fontStyleParam":true,"value":"font:normal normal normal 14px/1.4em \"open sans\",sans-serif;"},"loadMoreButtonFontColor":{"themeName":"color_15","value":"rgba(24,26,28,1)"},"loadMoreButtonColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"loadMoreButtonBorderColor":{"themeName":"color_15","value":"rgba(24,26,28,1)"},"arrowsColor":{"themeName":"color_19","value":"rgba(29,83,119,1)"},"oneColorAnimationColor":{"themeName":"color_11","value":"rgba(255,255,255,1)"},"responsive":false,"isAccessible":false,"allowLeanGallery":false,"layoutsVersion":2,"selectedLayoutV2":3,"isSlideshowFont":false,"externalInfoHeight":0,"externalInfoWidth":0},"container":{"top":"","bottom":"","left":"","right":"","width":637,"height":430,"position":"","avoidGallerySelfMeasure":true,"galleryWidth":637,"galleryHeight":295,"scrollBase":0}}
Features
A flight-hardened VCM can be ordered for any one of the following standard configurations:
-
DVI to ARINC 818
-
ARINC 818 to DVI
-
VGA to ARINC 818
In addition, custom analog conversions are also possible:
-
ARINC 818 to analog (NTSC, PAL, STANAG 3350, RS-170)
-
Analog (NTSC, PAL, STANAG 3350, RS-170) to ARINC 818
GRT will match the VCM to your ICD. VCMs have been through DO-160 testing and can be DO-254 certified, if required.
• 16 to 32 VDC power input per MIL-STD704F and RTCA DO-160F hardware qualification
• HIRF protected, EMI shielded design
• Robust 38999 Series circular connectors
